locations are highlighted in the geometry when you hover over the result as shown below. Values indicate how curvy or "swoopy" the curve or surface is at each point. When measuring edges and curves, the Minimum and Maximum Curvature Analysis tool that displays a fringe graph or color shading to represent the curvature alongĬurves or edges. Copy the value to the clipboard for pasting into Notes, etc. (Optional) Hover over a measurement value to display the Copy icon. You can measure to an axis of an origin object.
The reference can be a point, curve, edge, face, plane, axis, or origin. (Optional) Hold Alt and select a reference object. Triple-click on a body to display its total surface area. Selecting multiple faces displays their total area. distance between objects displays an exact measurement of the minimum distance between the objects you selected. Select points, curves, edges, or faces to display measurement information.Ĭtrl + Selecting multiple objects displays measurement between them as appropriate. Mouse over your design to preview the faces and edges eligible for measurement. in the Inspect group on the Measure Tools for displaying measurement properties of the edges, faces, and solids in your design.tab. Negative values are displayed for the results when you select an origin and the measurement is negative in the direction of one or more axes.Ĭlick Measure Tools for displaying measurement properties of the edges, faces, and solids in your design. Clicking on an object sets the dimensions in the results box. If you hold Alt and select a line or axis, then the preview shows the distance from the point under the mouse to the line. If you hold Alt and select any plane, then the preview shows the distance from the point under the mouse to the plane. This preview changes as you move your mouse over objects in the Design window Area in the user interface that displays your model or assembly. If you hold Alt and select an origin, then you will see a preview of the X, Y, and Z distance from the origin. You can hold Alt and select the origin or its axes as reference objects, and the distance in that direction (or all three) is displayed. The document origin is displayed by default. You can also modify the Precision and Angular Precision values in the Measure Tools for displaying measurement properties of the edges, faces, and solids in your design.
You can select units for measurement in the SpaceClaim Units options. or Move A tool used to translate or rotate geometry. Line creates a surface and pulling a surface creates a solid. Use the Pull tool to offset, extrude, revolve, sweep, Measurement values are selectable only when the tool is invoked within Pull Tool used to distort or deform geometry. and Move A tool used to translate or rotate geometry. When converting a sketch to 3D, pulling a Use the Pull tool to offset, extrude, revolve, sweep,ĭraft, and blend faces or to round, chamfer, or extrude edges. tool is accessible in the Ribbon and from within the Pull Tool used to distort or deform geometry. The Measure Tools for displaying measurement properties of the edges, faces, and solids in your design. Any values displayed on screen are automatically copied into the Clipboard and can be pasted into another document. tool to display measurements of the edges and faces in your design.
Use the Measure Tools for displaying measurement properties of the edges, faces, and solids in your design. You are here: Measuring and analyzing > Measuring > Displaying measurements
